breakpoint Mini Optical Power Meter , FTTH Portable Optical Power Meter ROSH

Handle Optical Power Meter Visual Fault Locator for breakpoint
Optical power meter refers to the instrument used to measure the
absolute optical power or the relative loss of optical power
through a fiber. In the optical fiber system, the measurement of
optical power is the most basic, very much like a multimeter in
electronics; in optical fiber measurement, optical power meter is a
heavy load table. By measuring the absolute power of the
transmitter or optical network, an optical power meter can evaluate
the performance of the optical equipment. When combined with a
stable light source, the optical power meter can measure connection
losses, test continuity, and help evaluate fiber link transmission quality.of fiber management.
Features:
* High sensitivity large operation scope
* 0.01dB resolution, showing test value and wavelength at same time
* Storage the reference value of the different wavelength, no data
lost when power off
* Battery supply, convenience for outside work
Operation wavelength850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm
Measuring Range-70 ~ +10dBm
Absolute Accuracy±0.2dB(in calibration conditions)
Linearity±0.03dB(-50 ~ +0dBm)
DisplaymW, uW, nW, dBm, dB, dBr
Test wavelength, battery power out(LOB)
ResolutionLog: 0.01dB, Linearity:0.1 ~ 1%
Output ModeFC/SC/ST are available(2.5mm)except LC
Data StorageEEPROM(Each wavelength storage one reference value)
Operation Temperature-35 ~ +70oC, 0% ~ 95%, RH (no condensing)
Storage Temperature-35 ~ +70oC, 0% ~ 95%, RH (no condensing)
BatteryTwo AA (No5)alkaline battery(continuous life time > 60hours)
Dimension&Weight62×125×23 mm (not include protection glove), ≤100g(without battery)
