    4 Motor Optical Fiber Fusion Splicer , Fujikura 41s Fusion Splicer CE certificate

    Ask Lasest Price
    Brand Name : Fujikura
    Model Number : FSM-41S/38S
    Certification : CE/ROSH/ISO9001
    Price : Negotiation
    Payment Terms : T/T, Western Union
    Supply Ability : 100 sets permonth
    Delivery Time : 5-10 working days
    • Product Details
    • Company Profile

    4 Motor Optical Fiber Fusion Splicer , Fujikura 41s Fusion Splicer CE certificate

    japan optic fiber optical clad alignment splicer fusion splicer fujikura FSM-41S kit FSM-38S

    Fujikur has been the pioneer in fusion splicer technology since 1978. Through our extensive knowledge in optical technology, we have been continuously challenging ourselves in creating splicers that are well known for their ruggedness and reliability worldwide. Working closely together with Fujikura’s strong team of technical experts, our worldwide network of distributors are committed to give the best technical support & service to our customers. Please try to peek at the construction site of near your home. You might find a Yellow BOX, which is one of the unique features of the Fujikura Splicers.
    User Friendly
    1. Easy Fiber Protection Sleeve Positioning
    The shape of the sheath clamp is optimized for the 60mm length protection sleeve. The
    length from splice point to the edge of the sheath clamp is 30mm. Therefore, it is easy
    to center the protection sleeve over the splice by using your finger as the reference
    splice point.
    2. New Concept Electrodes
    The 41S electrodes comes as an “assy” including the fixing screw. You can also rotate the
    screw by hand without tools. It enables easy electrode replacement.
    3. Universal Tube Heater
    The 41S fusion splicer can accommodate a max 6.0mm diameter heat sleeve before
    shrinking. As a result, it supports a wide range of protection sleeve sizes.
    4. Work Tray
    The work tray can transform into several shapes according to your optical installation style.
    Applicable fiberSingle / SMF(G.652/657), MMF(G.651), DSF(G.653), NZDSF(G.655)
    Cladding dia. / Sheath dia.125 um / Up to 3mm with sheath clamp
    Cleave length5mm to 16mm
    Splice mode / heating modeTotal 100 splice modes / 30 heating modes
    Typical splice loss*s0.03dB (SM), 0.01dB(MM), 0.05dB(DS) and 0.05dB(NZDS)
    Return loss>60dB
    Typical splice time6sec SM FAST, 9sec SM AUTO
    Typical tube heating time25sec FP-03, coating dia.250um
    Splice result storageLast 10,000 splices
    Viewing methods / magnification2 axis 2CMOS camera with 5.0”color LCD. 132X magnification.200X magnification after splicing
    Tension test1.96 to 2.25N
    Applicable protection sleeve60mm, 40mm and Fujikura micro sleeves
    No. of splice / heating per battery full chargeTypical 200 cycles with BTR-11*2
    Electrode lifeTypical 5000 splices
    Size / weight131W x 201Dx 79H mm/ 1300g (including battery)
    Operating condition

    Altitude : 0 to 5,000m above sea level, Wind : 15m/sec

    Temperature : -10 to 50deg C, Humidity : 0 to 95%RH, non-dew

    Resistance feature*4

    Shock resistance : 76cm (30inch) bottom surface drop

    Dust resistance : Exposure to dust ( 0.1 to 500μm dia. Alumina Silicate) ,IP5X

    Rain resistance : H=10mm/hr for 10min ,IPX2

    Other featuresPC software upgrade / data management
    TerminalsUSB 2.0 (Mini-B type) connector for PC communication.
