FST-18H Optical Fiber Fusion Splicer , FTTH Tumtec Splicing Machine 5000 arcs

Factory direct supply tumtec fiber optic fusion splicing machine FST-18H fibre optique fusion splicer

FST-18H is mainly used for fiber-to-home applications. FTTx Cladding Alignment Fusion Splicer,Auto splice mode manifest user-friendly design;Dust-proof,water-proof,high temperature resistance,adapting to various altitude and formidable nature conditions;4.3' ' high reslolution LCD touch screen with 380x magnification,visible clearly bare eyes;Packed with data chable 4800mAh battery,more than 230 times of splicing and heating;3 high-power white LEDs and illuminated keypads simplifies your work at night;Detachable multi function fixture,suitable for various fiber types.German CNC technique and integrated fiber-adjust frame, which make performance much stable.Built -in Japanese components and Korean chipset.

FST-18H Optical Fiber Fusion Splicer , FTTH Tumtec Splicing Machine 5000 arcs

Description:

1.The machine's appearance color is black and golden yellow. It is specially used for short distance work and maintenance from optical fiber to home.

2.The shielding cover is wind-proof, freeze-proof, quake-proof, water-proof, provide the protection for fiber; clear plastic button, for convenient operation, with handle and strap.

3.Large capacity battery up to 4800 mA, Port Ultra Mini USB 2.0.

4.There are four windproof covers (damp proof, dust proof, shock proof and frost proof).

5.FST-18H has three high-power LED white lights, light and dark operation more heart-saving.

6.The display can be adjusted to the optimum angle for easy operation.

Model	FST-18H
Compatible Fiber/Cable	0.25-3.0mm/Indoor Cable
Return Loss	≥60db
Splicing Time	6 seconds
Estimated Splice Loss	yes
Protection Sleeve Length	20-60mm
Heating Time	13~ 30 seconds
Results Storage	1000 records
Tension Test	1.5-2.0N
Fiber View & Magnification	X,Y,XY,X/Y:380×Magnification
Power Supply	AC Input 100-240V,DC Input 12-15V
Battery capacity	4800mAh battery capacity
Heating times	Quick heating time:13S,typical heating time:30S.
Terminal	USB 2.0
Weight	1.8 KG (including rubber Bumper)
Dimension	140W165L138Hmm (including rubber Bumper)
