Flexible Yokogawa AQ7280 OTDR 1310/1550nm With Touch Screen

Original Yokogawa AQ7280 OTDR 1310/1550nm OTDR in stock

The AQ7280 is the most flexible OTDR in our lineup due to a modular platform to create a variety of systems from a basic unit to units with filtered ports to test live traffic networks in applications from long haul, to metro, core and FTTH.

Flexible Yokogawa AQ7280 OTDR 1310/1550nm With Touch Screen

Festures:

1:Is simple, intuitive

AQ7280 Series have the industry's best 8.4 inches capacitive touch screen, support, and smart phones and other handheld devices with the same multi-touch function that allows users to locate and adjust the image size on the screen visually. AQ7280 Series models also have the same operation until the hard keys. Users can choose to use the touch screen or physical keys.

2:Nine models to meet the needs of a variety of measurement

AQ7280 series consists of nine models, including AQ7285A and AQ7283K. AQ7285A has industry-leading 50dB dynamic range, suitable for long distance measurement, and AQ7283K measure up to four different wavelengths. As a modular measurement unit, the user can change the measurement module in the field, which makes the AQ7280 series with unparalleled flexibility and convenience. By replacing the measuring unit, AQ7280 series can be flexibly due to new measurement of optical communication technology development needs arising.

Items			Specifications
Display			8.4-inch color TFT LCD (Resolution: 800x600, Multi-touch capacious touchscreen)
Electrical interface			Unit interface x1, Module interface x1,USB 2.0 x3 (TYPE Ax2, TYPE B (mini) × 1)
Remote control			USB TYPE B (mini),Ethernet (TCP/IP)
Data storage		Storage	Internal storage: ≥1000 waveforms, External storage:USB memory,SD card
		File format	Write:SOR,CSV,SET,BMP,JPG, CFG,PDF,Read: SOR,SET
Dimensions			Approx. 287 mm (W) x210 mm (H) x80 mm (D)(excluding projections)
Weight			Approx. 2.2 kg (including internal battery and protectors, excluding OTDR unit and options)
OTDR functions	Minimum readout resolution		Horizontal axis:1 cm, Vertical axis: 0.001 dB
	Group refractive index		1.30000 to 1.79999 (in 0.00001 steps)
	Distance unit		Km,mile, kf
	Measurement		Distance, Loss,Return loss, and Return loss between two arbitrary points
	Analysis		Multi Trace Analysis,Two-Way Trace Analysis, Difference Trace Analysis,Section Analysis, Macro Bending Analysis
	Other functions		Multi Fiber Project, Fault Locator,Work Completion Notice,File report, Auto event search, Pass/Fail judgment, Schedule Measurement (Option), Smart Mapper (Option) YOKOGAWA AQ7280 OTDR (1pc)
