2.55mm Interface Fiber Optic Light Pen For ATM Fiber System

Ask Lasest Price
Brand Name :	HYX
Model Number :	HYX-010
Certification :	CE/ROSH/IOS9001
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000sets
Delivery Time :	5-10 work days

Add to Cart

Product Details
Company Profile

2.55mm Interface Fiber Optic Light Pen For ATM Fiber System

Vfl fiber optic light pen ftth 5mw 10mw 20mw 30mw 50mw

fiber optic internet cable tester 650nm visual fault locator

Description:

650nm visual fault locator has the function of fiber identification and faults locator of SM or MM fiber, it is a helpful assistant to dead zone of OTDR, it is also a basic maintenance tool for fiber network, LAN, ATM fiber system and telecom network system.

r optic visual fault locator adopts 650nm laser diode as a light emitting device,the output power can be up to 1mw-20mw. It’s applied to single-mode or multi-mode fiber measurements.In the meantime, you can use SC / ST adapter and do not need to configure the conversion interface furthermore, it can optionally connect all frequently-used joint.It is an ideal tool to test various types of optic fiber patch cord, ribbon, bundle fiber optic pigtail and maintain a variety of fiber optic lines for you.
Wavelength: 650nm

Interface: SC, FC, ST, available FC-LC converter

2.55mm Interface Fiber Optic Light Pen For ATM Fiber System

Features:

mini compact, stable light source, LED lighting, automatic shutdown
Innovation: ergonomic, more comfortable to operate, more convenient to carry, weighing only 38g. Equipped with LED lights for easy operation at night, imported laser head, stronger penetration, longer distance and longer service life

Applications:

-Telecommunications Engineering and Maintenance

-CATV engineering and maintenance

-Cabling System

-Other fiber-optic project

HYX-001/005	HYX--010	HYX-020	HYX-030	HYX-050
Wavelength	650nm ± 20nm
Output Power *	> 1/5mW	> 10mW	> 20mW	> 30mW	>50mW
Dynamic Distance **	> 5 km	> 10 km	> 20 km	> 30 km	>50 km
Connector ***	2.5mm or 1.25mm Universal connector
Storage Temperature	-20 -- +60 °C, < 90%RH
Operating Temperature	-10 -- +50 °C, < 90%RH
Power Supply	AA * 2
Weight	About 80g
